• High luminous efficiency，30W Luminous flux4285lm;Whole lamp output light effiency >150LM/W.
• Unique second-time light distribution, no light pollution,no glare, noflickering.
• Modular structure making the lamp more easier and faster to be designed,easy to do replacement and maintaining.A variety of combinations can multiplyincrease the brightness and illumination.
• Modular concept, piece combinations as your require. Can satisfy anynumber of lanes and width combinations. With IP66 Protection, adapt to anyweather conditions.
• Impact Resistance, Shock-proof, Without Ultraviolet (UV) and Infrared(IR) Radiation: No filament and glass frames, avoid break of the traditionallamp,without harm to the human body.
• The CCT of Warm white、Neutral white、Purewhite to meet the needs of different occasions, eliminated the low colortemperature of the sodium lamp which cause the depressed mood.
• CHEM module design adopts the professional optical design of free-curve-surface, fully uses the features that LED light in directionally to improve theutilization of LED maximumly under offered a space-saving of lightefficiency,and makes shines more than 80% on the road,and avoids lightpollution maximumly caused by street lights.

Package:

• Inner Carton = 1 Set Weight：0.92KG

• 1 Outer Carton= 20 Set Weight：21.0KG

• Inner Carton Size : 320mm X 85mm X 70mm

• Outer Carton Size : 465mm X 340mm X 325mm

The entire series of LED CHEM Street Light Modular voltage range is DC29~32 volts.

All LEDs are in series connecting, considering different using conditions and places in the applications, please match with a constant current driver to drive the lamp.

Remark：

• The led module adopt special techniques to keep enough light effiency, please do not open the light engine ,otherwise there won’t have reparing gurantee.

• When customers in the process of matching the power supply,please match with the surge protector to ensure the safety. • The radiator has its own design peak, please do not exceed the maximum use of current so that ensure the light efficiency and lumen.

• All LEDs are in series connecting, considering different using conditions and places in the applications, please match with a constant current driver to drive the lamp.
