- Place of Origin: SHENZHEN
- Brand Name: LEYOND
- Model Number: 50W Single Modular
• high quality power supply, input voltage 100-277V. The power efficiency is morethan 90%, power factor greater than 0.98, UL compulsory certification.
• Adopting Lepower led light sources and ZAG lens technology, 8% lightefficiency higher than the same type lights in the market, with higher lighttransmittance up to 98%.
• Duct type thermal design, reduce the weight of the light and ensure goodheat dissipation, lower luminous decay, and also extend life span of the leds.Adopting the popular CHEM modular design, effectively reduce the followingmaintenance cost.
• Low energy consumption,matching high efficiency constant-current driver, 60%energy saving; with good resistance to over-current, over-voltage, lightning,high temperature, which fully ensure long life span and high stability of theproducts.
• Durable lights with long life span up to 50000 hours; No need frequentreplacements of lights and regular maintenance.
• Green environmental protection, no UV light and infrared radiation, nomercury pollution.
• Nice appearance and non-fouling properties, Protection class IP66.
• Work without strobe, fast transient response;A wide range of working voltage.
• 2pcs 1W chips are packaged in one led, which ensure high stability andalso reduce the death rate of the leds.
Warning:
Do Not Use Other Devices for LED high bay light Installation Such as Stabilizer, Regulator …etc
Do Not Open the Light Engine
Do Not Soak the high bay light into Water
Do Not Light up the System Without Grounding
Do Not Use Dimmer
Module Quantity | Dimension of Lights (L*328*98) | Net Weight |
1 | 399*328*98mm | 5.3kg |
Specification:
Electrical Specifications
Product Model | Module Quantity | Power | Input Voltage/Frequency | Input Current | Power Factor | Efficiency of the Driver |
LY-SL11050 | 1 | 50W | AC90~305V 50/60Hz | 0.64A/115VAC | >0.98/115VAC >0.95/230VAC | >93% |
Optical Specifications:
Product Model | Module Quantity | Power | Luminous Flux | Light efficiency | CRI | CCT | Lens Degree |
LY-SL11050 | 1 | 50W | 6500LM | 130lm/W | >45 >60 >65 | 2800-3000K 3000-3500K 4000-4500K 5000-5500K | 150°x70° |
Mechanical Specifications:
Module Quantity | Package Size | The gross weight/Carton | IP | Life Span | Material of Housing |
1 | 460*388*168mm | 6.5kg | IP66 | 50000hs | Aluminum alloy PC |
