- Place of Origin: SHENZHEN
- Brand Name: LEYOND
- Model Number: 5W A Series Ceiling
• COB led source, light efficiency 120lm/w
• Particular DIWL TM lens ,high efficiency>92%
• Anti-glare design
• Unique and stylish in look
• Advanced thermal management technology
| Product type | LY-CL1005WW | LY-CL1005PW |
| Color | WW | PW |
| Input voltage(V) | AC100-240V_ 50/60Hz / DC12V | |
| Power Consumption(W) | 5.5W(Max) | |
| Power Factor | >0.9 | |
| Beam Angle(o) | 24/38/60 | |
| CRI | 75 | 75 |
| Luminous Flux(lm) | 360 | 455 |
| Dimmable | optional | |
| Socket | -------- | |
| Lifetime(hrs) | 40000 | |
| Net weight(kg) | 0.22 | |
DIWLTM Optical Theory:
DIWL lens series, an unique and effective solutionfor LED spot design.
Structure
①COB LED source
②LED Chips
③Fly Eye Design
④Scales
• Operation Ambient Temperature -20 to 40°C,Relative Humidity 20~90%
• Input Voltage 100~240V AC, 50/60Hz
• Storage Ambient Temperature -40 to 85°C, RelativeHumidity 5~95%
Quality Warranty:
• Quality guaranteeis based on storing, installing ,operating and maintaining correctly inthe normal operation condition.
• It is not included in our maintainingrange when installing inappropriately,breaking the operating rules, and leading to the productsdamaging.
• Ourcompany will maintain the right to either repair, parts replacing,or products exchange during the quality warranty period
